实训台 LX320/LX360L型 车床_机械加工中心普通机床｜机加工设备_公司生产研制
|
型号 |
Model |
LX 320 |
LX 360L |
|
产品编号 |
Code No. |
P4232300 |
P4237300 |
|
加工范围 |
Capacity |
|
|
|
床身上*大回转直径 |
Swing over bed |
ø330mm |
ø360mm |
|
拖板上*大回转直径 |
Swing over cross slide |
ø190mm |
ø210mm |
|
马鞍槽内*大回转直径 |
Swing in gap diameter |
ø475mm |
ø490mm |
|
花盘前马鞍有效长度 |
Length of gap |
115mm |
115mm |
|
两顶尖中心距 |
Admits between |
1000mm |
1000mm |
|
主轴中心高 |
Center height |
165mm |
165mm |
|
床身宽度 |
Width of bed |
185mm |
185mm |
|
主轴 |
HEADSTOCK |
|
|
|
主轴端部 |
Spindle nose |
D1-4 |
D1-4 |
|
主轴通孔直径 |
Spindle bore |
ø38mm |
ø38mm |
|
主轴内孔锥度 |
Taper of spindle bore |
MT5 |
MT5 |
|
主轴转速范围 |
Range of spindle speed |
70-2000rpm |
70-2000rpm |
|
进给及螺纹 |
FEEDS AND THREADS |
|
|
|
小拖板*大行程 |
Top slide travel |
95mm |
95mm |
|
中拖板*大行程 |
Cross slide travel |
180mm |
180mm |
|
大丝杆规格 |
Lead screw thread |
4mm |
4mm |
|
车刀刀杆*大截面 |
Max.Section of tool |
16x16mm |
16x16mm |
|
公制螺纹范围 |
Threads metric pitches |
0.25-11mm |
0.4-7mm |
|
英制螺纹范围 |
Threads imperial pitches |
4-112T.P.I. |
8-112T.P.I |
|
尾座 |
TAILSTOCK |
|
|
|
尾座套筒直径 |
Quill diameter |
ø32mm |
ø32mm |
|
尾座套筒行程 |
Quill travel |
100mm |
100mm |
|
尾座套筒内孔锥度 |
Quill taper |
MT3 |
MT3 |
|
电机 |
MOTOR |
|
|
|
主电机功率 |
Main motor power |
1.5KW |
1.5KW |
|
冷却泵功率 |
Coolant pump power |
40W |
40W |
|
外形尺寸及重量 |
DIMENSION AND WEIGHT |
|
|
|
外形尺寸（长x宽x高） |
Overall dimension(LxWxH) |
1820x740x1240mm |
1870x740x124mm |
|
包装箱尺寸（长x宽x高） |
Packing size(LxWxH) |
1930x760x1450mm |
1970x760x1450mm |
|
净重/毛重 |
NW/GW |
520/640kg |
520/640kg |
