| Type | LU 3610 V |
| Item No | P340 3130 |
| Machine datas | |
| Electrical connection | 400 V / 3 Ph ~50 Hz |
| Main motor power | 4 kW |
| Coolant equipment | 40 W |
| Working areas | |
| Centre height | 180 mm |
| Centre width | 1'000 mm |
| Turning Ø over lathe bed | 356 mm |
| Turning Ø over cross slide | 220 mm |
| Turning Ø in the bed bridge | 516 mm |
| Length of bed bridge | 240 mm |
| Bed width | 205 mm |
| Speeds | |
| Spindle speed | 30 - 550 min-1 / 160 - 3000 min-1* |
| Number of steps | 2 steps, electrically adjustable speed |
| Headstock | |
| Spindle taper | MT 5 |
| Spindle seat | Camlock DIN ISO 702-2 Nr. 4 |
| Spindle drilling, rod passage | Ø 38 mm |
| Slide | |
| Travel top slide | 95 mm |
| Travel cross slide | 180 mm |
| Longitudinal feed in the range of | 0.043 - 0.653 mm/rev;42 feeds |
| Transverse feed in the range of | 0.015 - 0.220 mm/rev;42 feeds |
| Pitch - Metric in the range of | 0.45 - 7.5 mm/rev; 37 thread pitches |
| Pitch - Inch in the range of | 112 - 4 threads/1"; 28 thread pitches |
| Quadruple tool holder seat height | Max. 16 mm |
| Tailstock | |
| Tailstock seat | MT 3 |
| Tailstock - sleeve travel | 120 mm |
| Dimensions | |
| Length x width x height | 1'920 x 800 x 1'250 (DPA 1.490) mm |
| Net weight | 850 kg |
